Tenda Router - W568R Wireless N900 Concurrent Dual Band
Leírás
Standards 2.4GHz: IEEE802.11 n/g/b
5.0GHz: IEEE 802.11 n/a,
IEEE802.3, IEEE802.3u, IEEE802.3ab
Interface 1*10/100/1000M WAN port;
3*10/100/1000M LAN ports;
1*10/100/1000M IPTV port (function as a LAN port with IPTV disabled);
1*USB 2.0 port.
Antenna 3* internal antennas
Button 1*WPS/Reset button
Power Input: AC 100-240V~50/60Hz 0.3A;
Output: DC 12V 1.5A.
Dimensions (L*W*H) mm 125mm*30mm*188mm (stand not included)
LED 1* Power/Sys, 1* WPS, 1* 5G, 1* 2.4G, 1* WAN, 1* USB, 3*LAN, 1* IPTV
Wireless Features
Wireless Speed 2.4G: 450Mbps;
5G: 450Mbps.
Frequency Works over 2.4G and 5G concurrently
Basic Features Wireless : Enable/Disable;
SSID Broadcast: Enable/Disable;
Band: 2.4GHz, 5GHz;
Channel-2.4GHz: 1-13;
Channel-5GHz: 149, 153, 157, 161, 165;
Network Mode-2.4GHz: 11b/g/n mixed (default mode),11b/g mixed, 11b, 11g;
Network Mode-5GHz: 11a/n mixed (default mode),11a;
Connection List.
Security Wireless MAC Address Filter (Wireless Access Control);
WEP, WPA-PSK/WPA2-PSK, WPA/WPA2;
Wireless Security: Enable/Disable;
WPS fast encryption.
Software Features
Internet Connection Type PPPoE; Dynamic IP; Static IP.
Operating Mode Wireless Router Mode; WAP Mode WDS Mode.
DHCP Server DHCP Server;
DHCP Client List;
DHCP Reservation.
Virtual Server Port Forwarding;
DMZ Host;
UPnP.
Security Client Filter
MAC Filter
Website Filter
Remote Web Management
DDNS Yes
VPN Pass through Yes
Other Bandwidth control;
USB Sharable: storage & printing
IPTV capable;
Guest Network Access;
MAC Clone;
Traffic Statistics;
Backup & Restore configurations
Firmware upgradeable via browser.
Others
Package Contents W568R
Power Adapter
Ethernet Cable
Quick Install Guide
Resource CD
Temperature Operating Temperature: 0? ~ 40?;
Storage Temperature: -40? ~ 70?.
Humidity Operating Humidity:10% ~ 90% RH non-condensing;
Storage Humidity: 5% ~ 90%RH non-condensing.
Factory Defaul Settings IP Address: 192.168.0.1
Login User name/Password: admin/admin
Related Products W522U, N80, N60
Certificates CE, FCC, RoHS
